如何使用Core Animation创建自定义缓动功能？

3回答

慕后森

我找到了这个：可可与爱-核心动画中的参数加速曲线但是我认为可以通过使用块使其变得更简单，更易读。因此，我们可以在CAKeyframeAnimation上定义一个类别，如下所示：CAKeyframeAnimation + Parametric.h：// this should be a function that takes a time value between //  0.0 and 1.0 (where 0.0 is the beginning of the animation//  and 1.0 is the end) and returns a scale factor where 0.0//  would produce the starting value and 1.0 would produce the//  ending valuetypedef double (^KeyframeParametricBlock)(double);@interface CAKeyframeAnimation (Parametric)+ (id)animationWithKeyPath:(NSString *)path       function:(KeyframeParametricBlock)block      fromValue:(double)fromValue      toValue:(double)toValue;CAKeyframeAnimation + Parametric.m：@implementation CAKeyframeAnimation (Parametric)+ (id)animationWithKeyPath:(NSString *)path       function:(KeyframeParametricBlock)block      fromValue:(double)fromValue      toValue:(double)toValue {  // get a keyframe animation to set up  CAKeyframeAnimation *animation =     [CAKeyframeAnimation animationWithKeyPath:path];  // break the time into steps  //  (the more steps, the smoother the animation)  NSUInteger steps = 100;  NSMutableArray *values = [NSMutableArray arrayWithCapacity:steps];  double time = 0.0;  double timeStep = 1.0 / (double)(steps - 1);  for(NSUInteger i = 0; i < steps; i++) {    double value = fromValue + (block(time) * (toValue - fromValue));    [values addObject:[NSNumber numberWithDouble:value]];    time += timeStep;  }  // we want linear animation between keyframes, with equal time steps  animation.calculationMode = kCAAnimationLinear;  // set keyframes and we're done  [animation setValues:values];  return(animation);}@end现在用法将如下所示：// define a parametric functionKeyframeParametricBlock function = ^double(double time) {  return(1.0 - pow((1.0 - time), 2.0));};if (layer) {  [CATransaction begin];    [CATransaction       setValue:[NSNumber numberWithFloat:2.5]      forKey:kCATransactionAnimationDuration];    // make an animation    CAAnimation *drop = [CAKeyframeAnimation       animationWithKeyPath:@"position.y"      function:function fromValue:30.0 toValue:450.0];    // use it    [layer addAnimation:drop forKey:@"position"];  [CATransaction commit];}我知道这可能不像您想要的那么简单，但这只是一个开始。

0 0

繁星coding

从iOS 10开始，可以使用两个新的计时对象更轻松地创建自定义计时功能。1）UICubicTimingParameters允许将三次贝塞尔曲线定义为缓动函数。let cubicTimingParameters = UICubicTimingParameters(controlPoint1: CGPoint(x: 0.25, y: 0.1), controlPoint2: CGPoint(x: 0.25, y: 1))let animator = UIViewPropertyAnimator(duration: 0.3, timingParameters: cubicTimingParameters)或仅在动画设计器初始化时使用控制点let controlPoint1 = CGPoint(x: 0.25, y: 0.1)let controlPoint2 = CGPoint(x: 0.25, y: 1)let animator = UIViewPropertyAnimator(duration: 0.3, controlPoint1: controlPoint1, controlPoint2: controlPoint2) 这项很棒的服务将帮助您为曲线选择控制点。2）UISpringTimingParameters使开发人员可以控制阻尼比，质量，刚度和初始速度来创建所需的弹簧性能。let velocity = CGVector(dx: 1, dy: 0)let springParameters = UISpringTimingParameters(mass: 1.8, stiffness: 330, damping: 33, initialVelocity: velocity)let springAnimator = UIViewPropertyAnimator(duration: 0.0, timingParameters: springParameters)持续时间参数仍在Animator中显示，但在春季计时中将被忽略。如果这两个选项还不够，您还可以通过确认UITimingCurveProvider协议来实现自己的时序曲线。

0 0

白板的微信

创建自定义计时功能的一种方法是使用CAMediaTimingFunction中的functionWithControlPoints ::::工厂方法（也有相应的initWithControlPoints :::: init方法）。这是为您的计时功能创建贝塞尔曲线。它不是任意曲线，但贝塞尔曲线非常有力且灵活。掌握控制点需要一些实践。提示：大多数绘图程序都可以创建贝塞尔曲线。进行这些操作将使您对用控制点表示的曲线产生视觉反馈。在这个链接指向苹果的文档。关于如何从曲线构造预构建函数的内容很简短，但很有用。编辑：以下代码显示了一个简单的反弹动画。为此，我创建了一个合成的计时函数（值和计时 NSArray属性），并为动画的每个片段赋予了不同的时间长度（keytimes属性）。这样，您可以合成贝塞尔曲线以为动画合成更复杂的时序。这是一篇有关此类动画的好文章，并提供了不错的示例代码。- (void)viewDidLoad {    UIView *v = [[UIView alloc] initWithFrame:CGRectMake(0.0, 0.0, 50.0, 50.0)];    v.backgroundColor = [UIColor redColor];    CGFloat y = self.view.bounds.size.height;    v.center = CGPointMake(self.view.bounds.size.width/2.0, 50.0/2.0);    [self.view addSubview:v];    //[CATransaction begin];    CAKeyframeAnimation * animation;     animation = [CAKeyframeAnimation animationWithKeyPath:@"position.y"];     animation.duration = 3.0;     animation.removedOnCompletion = NO;    animation.fillMode = kCAFillModeForwards;    NSMutableArray *values = [NSMutableArray array];    NSMutableArray *timings = [NSMutableArray array];    NSMutableArray *keytimes = [NSMutableArray array];    //Start    [values addObject:[NSNumber numberWithFloat:25.0]];    [timings addObject:GetTiming(kCAMediaTimingFunctionEaseIn)];    [keytimes addObject:[NSNumber numberWithFloat:0.0]];    //Drop down    [values addObject:[NSNumber numberWithFloat:y]];    [timings addObject:GetTiming(kCAMediaTimingFunctionEaseOut)];    [keytimes addObject:[NSNumber numberWithFloat:0.6]];    // bounce up    [values addObject:[NSNumber numberWithFloat:0.7 * y]];    [timings addObject:GetTiming(kCAMediaTimingFunctionEaseIn)];    [keytimes addObject:[NSNumber numberWithFloat:0.8]];    // fihish down    [values addObject:[NSNumber numberWithFloat:y]];    [keytimes addObject:[NSNumber numberWithFloat:1.0]];    //[timings addObject:GetTiming(kCAMediaTimingFunctionEaseIn)];    animation.values = values;    animation.timingFunctions = timings;    animation.keyTimes = keytimes;    [v.layer addAnimation:animation forKey:nil];       //[CATransaction commit];}

0 0
